1959 1960 Cadillac WITHOUT Air Conditioning (A/C) Aluminum Radiator REPRODUCTION

SPECIAL ORDER. MAY TAKE 2-3 WEEKS TO SHIP FROM THE DATE OF YOUR ORDER.

INTERNATIONAL SHIPPING IS AN ESTIMATE.

REPRODUCTION. You are purchasing an aluminum TIG welded dual-core radiator. The tanks are polished OE style to match the original appearance and overall look. These can be painted if desired. There are 16 corrugated fins per inch, giving more surface area and more thermal transfer. All radiators are pressure tested to ensure quality performance. These have the original style brackets for easy installation on the original 390 V8 Engine. For some models, trimming of the lower outlet may be required for installation. This lower outlet has a larger upward angle than what was originally provided on the car. The image is a representation of the product, it may look slightly different but the positioning of the hoses and brackets will be the same.

These radiators are made from uncoated aluminum, due to the manufacturing process they may come with some dings and scratches that will not affect the performance of the radiator.

ATTRIBUTES:

Transmission Cooler Line Inlet/Outlet Size: 1/2-20

Radiator Core Size: 25.5 Inches X 17.75 Inches X 3 Inches

Radiator Inlet Connector Size: 1.75 Inches

Radiator Outlet Connector Size: 1.75 Inches

Hose Diameter: 1 Inch Per Hose

Material: 100% Aluminum

FITS:

1959-1960 Cadillac Models WITHOUT Air Conditioning (A/C)
