1965 1966 1967 1968 Cadillac (See Details) Gas Tank Kit With Sending Unit And Straps REPRODUCTION

INTERNATIONAL SHIPPING IS AN ESTIMATE

REPRODUCTION. You are purchasing a replacement gas tanks sending unit, and metal straps with rubber insulation pads and bolts. This tank is made from steel with a grey painted finish and anti-rust coating. Image is a representation of the product, you will receive the correct product for your vehicle.

Please see below for dimensions to ensure proper fitment.

The sending unit mount should be oiled prior to installation. Use a lubricant like WD-40 in the two holes on the back of the mount, then move the float arm up and down a few times. This sending unit produces up to 90 ohms. If you want to test your sending unit, please see our "Instructions" tab.

PLEASE NOTE: This gas tank is approximately 4 gallons less than the original gas tank. There will be a void of approximately 4 inches to the side of the tank in the under body cavity of the vehicle. This will not affect performance and will still bolt in the same locations as the original.

FITS:

1965-1968 Cadillac Models EXCEPT Commercial Chassis and Front Wheel Drive (FWD) Models

THIS KIT INCLUDES:

1 Regular Steel Gas Tank

1 Gas Tank Sending Unit

1 Sending Unit Replacement Gasket

2 Gas Tank Straps

2 Rubber Mounting Straps

2 Bolts

GAS TANK ATTRIBUTES:

Volume: 21 Gallons

Length: 36.25 Inches

Width: 28 Inches

Depth: 6 Inches

(All measurements are approximate)

STRAP ATTRIBUTES:

Overall Length (From End to End): 38.5 Inches

Strap Width: 1.0625 Inches

(All measurements are approximate)
